AMHD1860RLF

View PDF

18"x16"x10" AMHD-R Series fiberglass wall mount enclosure assembly with hinged window cover and stainless-steel snap latch

AMHD1860RLF

$361.34

Fiberglass enclosure with hinged window cover and snap latch

  • Availability:

    For up-to-date delivery on this product, please contact us at 1-800-722-2679 or sales@alliedmoulded.com

  • Enclosure Type: JIC Size
  • Cover Type: Opaque
  • Closure Type: 2-Screw
  • Mounting Description: Nonmetal flange fastened to back side brass insert
  • Height: 18.24 in 463.296 mm
  • Width: 16.24 in 412.496 mm
  • Depth: 9.94 in 252.476 mm
  • Usable Depth: 11.01 in 279.654 mm
  • Volume: 3519 cu. in. 57666204.9 cu mm

Product Info

  • Brand: AM Series
  • UPC: 85339994763
  • UNSPSC: 39121324
  • Carton Quantity: 1
  • Carton Weight: 24 lbs 10.886 kg
  • Country of Origin: United States of America
  • Color: Gray (RAL 7035)
  • Material: ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
  • Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), Brass inserts, Plated carbon steel internal hardware, Polycarbonate mounting brackets, Polyurethane (FIP) Formed-In-Place gasket system
  • Features:

    Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus nonmetallic mounting brackets and a gasket system encased in a continuous channel on the cover.

  • Application:

    Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.

  • Standards:

    UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175

    Complies with:
    1. EN / IEC 60204-1 and 60529 Type IP66
    2. RoHS directive



     WARNING – PROP 65
    Click here for more information!

Online Order Notice

Outside the USA? Please call 1-800-722-2679 to talk with one of our customer service specialists! Online orders for USA customers only.

Description

18″x16″x10″ AMHD-R Series fiberglass wall mount enclosure assembly with hinged window cover and stainless-steel snap latch

Additional information

Weight 24 lbs
Dimensions 13 × 21 × 24 in
