AMHMI142CCL

View PDF

14"x12" HMI Cover Kit with hinged clear cover and stainless-steel snap latch

AMHMI142CCL

$138.72

HMI Cover Kit with hinged clear cover and snap latch

SKU: 85339991960 Category:
  • Availability:

    For up-to-date delivery on this product, please contact us at 1-800-722-2679 or sales@alliedmoulded.com

  • Cover Type: Clear Polycarbonate
  • Closure Type: Metal Snap Latch
  • Mounting Description: 10 Screws
  • Height: 13.95 in 354.33 mm
  • Width: 12.07 in 306.578 mm
  • Depth: .96 in 24.384 mm
  • Usable Depth: 2.2 in 55.88 mm
  • Volume: 370 cu. in. 6063227 cu mm

Product Info

  • UPC: 85339991960
  • UNSPSC: 39121302
  • Carton Quantity: 1
  • Carton Weight: 5 lbs 2.268 kg
  • Country of Origin: United States of America
  • Color: Gray (RAL 7035) with clear cover
  • Material: Polycarbonate frame and clear polycarbonate cover
  • Additional Materials: 316 stainless steel external hardware, Polyurethane (FIP) Formed-In-Place gasket system
  • Features:

    Non-corrosive, non-conductive, light weight with lower installation cost and longer life cycle cost compared to steel. Rigid design with a gasket system encased in a continuous channel on the cover and frame. Open back frame design with an opening size of 12.49″ x 10.71″ and is a UL recognized component for use with NEMA 4X enclosures. *Will fit Allied Moulded enclosure sizes 16â€?x14â€? and larger.

  • Application:

    Cover and protect electrical and electronic controls including HMI (Human Machine Interface) instruments, touch pad controllers and pushbuttons mounted on the surface of NEMA 4X enclosures. No need to open the enclosure to view electronics or perform maintenance, decreasing arc flash risks and safety hazards.

  • Standards:

    Meets Requirements: ANSI/UL50, ANSI/UL50E, and ANSI/UL508A; File No. E487574

    UL® listed and recognized component for use with enclosure products Types 1, 2, 3, 3R, 4, 4X, 12 and 13.

    Complies With:
    1. EN / IEC 60204-1 and 60529 Type IP66
    2. RoHS directive

     WARNING – PROP 65
    Click here for more information!

Online Order Notice

Outside the USA? Please call 1-800-722-2679 to talk with one of our customer service specialists! Online orders for USA customers only.

Description

14″x12″ HMI Cover Kit with hinged clear cover and stainless-steel snap latch

Additional information

Weight 5 lbs
Dimensions 5 × 16 × 16 in
