AMHMI66CX 6screw liftoff Inspection Window Kit with clear cover

AMHMI66CX

View PDF

6-screw lift-off 6x6 Inspection Window Kit with clear cover

AMHMI66CX

$25.39

6-screw lift-off Inspection Window Kit with clear cover

SKU: 85339991991 Categories: , ,
Find Rep.
  • Availability:

    For up-to-date delivery on this product, please contact us at 1-800-722-2679 or sales@alliedmoulded.com

  • Cover Type: Opaque
  • Closure Type: 4-Screw Lift-Off
  • Mounting Description: 4 Screws
  • Height: 6.5 in 165.1 mm
  • Width: 6.5 in 165.1 mm
  • Depth: 0.6 in 15.24 mm
  • Usable Depth: 0.47 in 11.938 mm

Product Info

  • UPC: 85339991991
  • UNSPSC: 39121302
  • Carton Quantity: 1
  • Carton Weight: 1 lbs 0.454 kg
  • Country of Origin: United States of America
  • Color: Gray (RAL 7035)
  • Material: Polycarbonate frame and cover
  • Additional Materials: Brass inserts, Plated carbon steel internal hardware, Polyurethane (FIP) Formed-In-Place gasket system
  • Features:

    Rigid clear window design with a gasket system encased in a continuous channel to provide an inspection point to see inside the enclosure, but also seal to the exterior of the enclosure and maintain it’s intended rating. UL recognized component for use with NEMA 4X enclosures.

  • Application:

    Inspection window for use on the exterior walls of NEMA Type 4X enclosures which allows the end user a viewing hole to see important equipment housed inside without having to access the enclosure.

  • Standards:

    Meets Requirements: ANSI/UL50, ANSI/UL50E, and ANSI/UL508A; File No. E487574

    UL® listed and recognized component for use with enclosure products Types 1, 2, 3, 3R, 4, 4X, 12 and 13.

    Complies With:
    1. EN / IEC 60204-1 and 60529 Type IP66
    2. RoHS directive

     WARNING – PROP 65
    Click here for more information!

Documents

Online Order Notice

Outside the USA? Please call 1-800-722-2679 to talk with one of our customer service specialists! Online orders for USA customers only.

Description

PDF Button

6-screw lift-off 6×6 Inspection Window Kit with clear cover

Additional information

Weight 1 lbs
Dimensions 2 × 9 × 10 in
