AMP1084CC Polycarbonate enclosure with 4screw liftoff clear cover

AMP1084CC

View PDF

10"x8"x4" POLYLINE® polycarbonate wall mount enclosure assembly with 4-screw lift-off clear cover

AMP1084CC

$69.29

Polycarbonate enclosure with 4-screw lift-off clear cover

SKU: 85339993148 Categories: , ,
Find Rep.
  • Availability:

    For up-to-date delivery on this product, please contact us at 1-800-722-2679 or sales@alliedmoulded.com

  • Enclosure Type: JIC Size
  • Cover Type: Clear Polycarbonate
  • Closure Type: 4-Screw Lift-Off
  • Mounting Description: Nonmetal feet fastened to back side brass inserts
  • Height: 9.93 in 252.222 mm
  • Width: 8.15 in 207.01 mm
  • Depth: 3.94 in 100.076 mm
  • Usable Depth: 4.06 in 103.124 mm
  • Volume: 393 cu. in. 6440130.3 cu mm

Product Info

  • Brand: POLYLINE®
  • UPC: 85339993148
  • UNSPSC: 39121324
  • Carton Quantity: 1
  • Carton Weight: 3 lbs 1.361 kg
  • Country of Origin: United States of America
  • Color: Gray (RAL 7035) with clear cover
  • Patents: U.S. Patent No. 7,572,975
  • Material: Polycarbonate box and clear polycarbonate cover
  • Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), Brass inserts, Plated carbon steel internal hardware, Polycarbonate mounting brackets, Polyurethane (FIP) Formed-In-Place gasket system
  • Features:

    Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus nonmetallic mounting brackets and a gasket system encased in a continuous channel on the cover.

  • Application:

    Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.

  • Standards:

    UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 6P, 12 and 13; File No. E120175

    Complies with:
    1. EN / IEC 60204-1 and 60529 Type IP66 and units rated 6P are IP68 (submersible up to 24 hours at a depth of 6 feet/1.8 meters)
    2. RoHS directive



     WARNING – PROP 65
    Click here for more information!

Documents

Online Order Notice

Outside the USA? Please call 1-800-722-2679 to talk with one of our customer service specialists! Online orders for USA customers only.

Description

PDF Button

10″x8″x4″ POLYLINE® polycarbonate wall mount enclosure assembly with 4-screw lift-off clear cover

Additional information

Weight 3 lbs
Dimensions 6 × 10 × 12 in
