AM363616L Fiberglass enclosure with hinged cover and snap latch

AM363616L

View PDF

36"x36"x16" Empire Series fiberglass wall mount enclosure assembly with hinged cover and stainless-steel snap latches

AM363616L

$2,955.33

Fiberglass enclosure with hinged cover and snap latch

SKU: 85339940036 Categories: , ,
Find Rep.
  • Availability:

    For up-to-date delivery on this product, please contact us at 1-800-722-2679 or sales@alliedmoulded.com

  • Enclosure Type: Wall Cabinets
  • Cover Type: Opaque
  • Closure Type: Metal Snap Latch
  • Mounting Description: Molded flange
  • Height: 36.04 in 915.416 mm
  • Width: 36.04 in 915.416 mm
  • Depth: 14.14 in 359.156 mm
  • Usable Depth: 14.27 in 362.458 mm
  • Volume: 20366 cu. in. 333739678.6 cu mm

Product Info

  • Brand: Empire Series
  • UPC: 85339940036
  • UNSPSC: 39121324
  • Carton Quantity: 1
  • Carton Weight: 79 lbs 35.834 kg
  • Country of Origin: United States of America
  • Color: Gray (RAL 7035)
  • Material: ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
  • Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), EPDM Spring loaded gasket, Plated alloy steel bonding fastener, Plated carbon steel internal hardware
  • Features:

    Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus molded-in mounting flanges and a spring loaded gasket system.

  • Application:

    Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.

  • Standards:

    UL 508A, UL 50 and UL 50E Types 1, 4, and 4X; File No. E120175

    Complies with:
    1. EN / IEC 60204-1 and 60529 Type IP66
    2. RoHS directive



     WARNING – PROP 65
    Click here for more information!

Documents

Online Order Notice

Outside the USA? Please call 1-800-722-2679 to talk with one of our customer service specialists! Online orders for USA customers only.

Description

PDF Button

36″x36″x16″ Empire Series fiberglass wall mount enclosure assembly with hinged cover and stainless-steel snap latches

Additional information

Weight 79 lbs
Dimensions 20 × 41 × 45 in
